How to Clean Up Sponsor Vector Art Before Printing
Even a good vector file can cause print problems: white fills that block the garment, missing font outlines, colors outside your printer's range. Here is the 5-step preflight that catches every common issue.
Why Vector Files Still Need Cleanup
A vector file from a sponsor or client is often built for screen use, not print. Colors may be in RGB mode. Fonts may not be outlined. White backgrounds may exist as invisible fills that will print as an opaque white box on the transfer.
Running a quick preflight on every incoming vector file takes 5 minutes and prevents a reprint conversation.
Check 1: Remove the White Background
Open the file in Illustrator or Inkscape. Look for a white rectangle behind the logo. It may be grouped with the artwork or sitting on a separate layer. Delete it. The transfer film should be fully transparent wherever there is no ink.
If you miss a white fill and print it, you get an opaque white box around the logo on the garment. It looks fine on white shirts and wrong on everything else.
Check 2: Outline All Fonts
If a logo contains text and the fonts are not outlined, anyone opening the file without that font installed will see font substitution. On a production system, this causes silent errors where the wrong typeface prints.
In Illustrator: Select All, then Type, then Create Outlines. Save a copy rather than the original. Fonts become vector paths and the file is now portable across any system.
Check 3: Verify Color Mode and Spot Colors
DTF printing works from a rasterized output. CMYK values translate more predictably than RGB. Check the document color mode under File, Document Color Mode, and switch to CMYK if it is set to RGB.
Sponsor logos sometimes contain Pantone spot colors. Convert those to CMYK process equivalents. The conversion is not always perfect, but it is far better than leaving spot colors undefined for the RIP.
Check 4: Expand and Flatten Before Export
Complex effects including drop shadows, gradients applied to strokes, and clipping masks from outside the artboard can cause unexpected output. Expand all appearances (Object, Expand Appearance) and flatten transparency before exporting.
Export the final file as a 300 DPI PNG with a transparent background. That is the correct delivery format for DTF print submission.
- Delete all white background rectangles or fills
- Outline all fonts before saving the production file
- Convert to CMYK and resolve any Pantone spot colors
- Expand appearances and flatten transparency
- Export as 300 DPI PNG with transparent background
